GUIDE

This guide is intended to help with syntax. See the prelude section for pre-defined functions and variables. See the tutorials page for tutorials on how to write code.

Data Types
- int
  int
  Integer values, such as 2, -4 and 254.
- float
  float
  Floating point values, such as 2.0, -4.72 and 254.2681.
- string
  string
  String values, such as "hello, world!", "haha" and "33".
- boolean
  boolean
  Boolean values True and False.
- colour
  colour
  Colour values for drawing on the canvase, See the prelude for more.
- list
  list[element_type]
  List values. Note the element type must be correctly specified. Examples are [1,2,3], [["hello"], ["world"]] and [].
Variables
- declaration
  name: type
  A variable must first be declared with a type before it can be used
- assignment
  name = value
- increment
  name += value
  Only applicable to integer values. Equivalent to name = name + value .
- decrement
  name -= value
  Only applicable to integer values. Equivalent to name = name - value .
Expressions
- logic

  Applicable to boolean values. and, or and not.
- mathematical

  Applicable to numerical values. +, -, *, **, /, // and %.
- relational

  Applicable to comparable values. >, <, ==, !=, <= and >=.
Selection Statements
- if
  if condition: statements elif condition: statements else: statements
Loops
- while
  while condition: statements
- for
  for ident in list: statements
Function
- function
  def name(parameter: parameter_type) -> return_type: statements
  Values can be returned with return
- procedure
  def name(parameter: parameter_type): statements
  Equivalent to a function which returns a None type

Can't find what you're looking for?

Check the tutorials page for more!

PRELUDE

The prelude is all the pre-defined functions and variables available to use. For help with the See the tutorials page for tutorials on how to write code.

Terminal Functions
- print
  print(expr)
  Prints the value of the expression to the terminal.
- print_str
  print_str(expr)
  Prints the value of the expression as a string to the terminal.
- clear_terminal
  clear_terminal()
  Clears the terminal.
- input
  input(message: str) -> str
  Displays message to the user, and returns their input as a string.
Type Functions
- str
  str(expr) -> str
  Where possible returns the string representation of expr.
- int
  int(expr) -> int
  Where possible parses the integer representation of expr.
- float
  float(expr) -> float
  Where possible parses the float representation of expr.
- len
  len(expr) -> int
  Where possible returns the length of expr.
- type
  type(expr) -> str
  Returns the name of the type of expr.
Math Functions
- round
  round(n: float) -> int
  Rounds the value of n using bankers rounding.
- random_int
  random_int(from: int, to: int) -> int
  Returns a random integer between from and to.
- random_float
  random_float(from: float, to: float) -> float
  Returns a random float between from and to.
- pi
  pi: int
  The value of π.
String Functions
- upper
  str.upper()
  Returns the uppercase of str.
- lower
  str.lower()
  Returns the lowercase of str.
- replace
  str.replace(s1: str, s2: str)
  Returns a string will all occurances of s1 replaced with s2.
- split
  str.split(d: str)
  Returns a list of strings of str split on all occurances of d.
- join
  str.join(ss: list[str])
  Returns a string from joining all strings in ss using d.
- isnumeric
  str.isnumeric() -> bool
  Returns true if all characters in str are numbers.
List Functions
- append
  l.append(elem)
  Appends elem to the list l.
- remove
  l.remove(elem)
  Removes the first instance of elem from the list l.
- count
  l.count(elem)
  Returns the total of elems present in the list l.
- range
  range(f: int, t: int) -> list[int]
  Returns the list of values from f to t.
Drawing Functions
- line
  line(x1: int, y1: int, x2: int, y2: int)
  Draws a line from (x1,y1) to (x2,y2).
- rect
  rect(x: int, y: int, w: int, h: int)
  Draws a rectangle of dimensions w by h on the canvas at position (x,y).
- circle
  circle(x: int, y: int, r: int)
  Draws a circle with radius r on the canvas at position (x,y).
- ellipse
  ellipse(x: int, y: int, r1: int, r2: int)
  Draws an ellispe with horizontal radius r1 and vertical radius r2 at position (x,y).
- arc
  arc(x: int, y: int, r: int, f: int, t: int)
  Draws an arc with radius r on the canvas at position (x,y) from f degrees to t degrees.
- sect
  sect(x: int, y: int, r: int, f: int, t: int)
  Draws a sector with radius r on the canvas at position (x,y) from f degrees to t degrees.
- triangle
  triangle(x1: int, y1: int, x2: int, y2: int, x3: int, y3: int)
  Draws a triangle with corners at positions (x1,y1), (x2,y2) and (x3,y3).
- polygon
  polygon(xs: list[int], ys: list[int])
  Draws a polygon with corners at positions (xi,yi) from xs and ys.
- img
  img(x: int, y: int, w: int, h: int url: string)
  Draws the image loaded from the url at position (x,y) with width w and height h.
- text
  text(x: int, y: int, t: string)
  Draws the text t at position (x,y).
Colour Functions
- rbg
  rgb(r: int, g: int, b: int) -> colour
  Returns the colour for the respecive red, green and blue values.
- rbga
  rgba(r: int, g: int, b: int, a: float) -> colour
  Returns the colour for the respecive red, green and blue and alpha values. Alpha is opacity, in the range 0.0 to 1.0.
- red
  red: colour
  The built in colour red, equivalent to rgb(240, 51, 51).
- green
  green: colour
  The built in colour green, equivalent to rgb(98, 203, 166).
- blue
  blue: colour
  The built in colour blue, equivalent to rgb(117, 117, 232).
- pink
  pink: colour
  The built in colour pink, equivalent to rgb(197, 89, 146).
- yellow
  yellow: colour
  The built in colour yellow, equivalent to rgb(221, 192, 107).
- white
  white: colour
  The built in colour white, equivalent to rgb(255, 255, 255).
- black
  black: colour
  The built in colour black, equivalent to rgb(0, 0, 0).
- transparent
  transparent: colour
  The built in colour transparent, equivalent to rgba(0, 0, 0, 0.0).
Canvas Functions
- width
  width: int
  The width of the canvas in pixels.
- height
  height: int
  The height of the canvas in pixels.
- line_colour
  line_colour(c: colour)
  Sets the canvas line colour to c.
- fill_colour
  fill_colour(c: colour)
  Sets the canvas fill colour to c.
- line_width
  line_width(w: int)
  Sets the canvas line width to w.
- font_size
  font_size(s: int)
  Sets the canvas font size to s.
- translate
  translate(x: int, y: int)
  Translates the canvas by (x,y).
- rotate
  rotate(a: int)
  Rotates the canvas by angle a in degrees.
- scale
  scale(x: float, y: float)
  Scales the canvas size by (x,y).
- frame_rate
  frame_rate(s: int)
  Sets the frame rate of the definable draw function.
- stop_draw
  stop_draw(s: int)
  Stops the execution of the definable draw function.
Definable Functions
- draw
  def draw():
  Is called at frame_rate, intended for animations and games on the canvas.
- left_pressed
  def left_pressed():
  Is called whenever the left arrow key is pressed.
- right_pressed
  def right_pressed():
  Is called whenever the right arrow key is pressed.
- up_pressed
  def up_pressed():
  Is called whenever the up arrow key is pressed.
- down_pressed
  def down_pressed():
  Is called whenever the down arrow key is pressed.
- space_pressed
  def space_pressed():
  Is called whenever the space key is pressed.

Can't find what you're looking for?

Check the tutorials page for more!
